Icemedal IMT5 5 Tons Per Day Automatic Tube Ice Maker Machine With Low Power Consumption



MOQ:1 set

Warranty:12 months

Payment:T/T, Western Union, Money Gram, L/C

Lead time:40 days after getting deposit

After-sales Service Provided:Engineers available to service overseas

  • IMT5

  • Icemedal

Automatic 5 Tons Per Day Tube Ice Maker Machine From Icemedal

|Product Description

5 Tons tube ice machine is a good choice for community ice business,The ice plant design provided is able to make the machine operation during night,to make more profit for you.A complete tube ice plant normally is equipped with water fltter,water tank,ice tube maker machine,ice bin,ice packing machine,cold storage and ice delivery car.we are able to provide you with the whole line of products.There is no need for you to buy all those products one by one.

ice tube maker machine details 1

ice tube maker machine details 2


 Tube Ice Application

tube ice application

Tube Ice are widely used in food preservation, medical applications, KTV, banquet hall, drinks modulation, hotels, bars,restaurants, fast food shops, cold drinks shop, beer room and other places need ice.


 Production Process

ice tube maker machine production of process

Tube Ice Machine Parameter

IMT 5 Tons Tube Ice Making Machine Parameters
Name Unit Parameters
Tube Diameter mm Φ22 Φ28 Φ35
Compressor Parameter Model 6HE-28
Cooling capacity(kW) 57
Power(kw) 20
Condenser Model WN-25
Heat Exchange(kW) 95.2
Condensing Temperature Degree Celsius(℃) 40
Evaporating Temperature Degree Celsius(℃) -12
Ambient Temperature Degree Celsius(℃) 32
Water Temperature Degree Celsius(℃) 20
Voltage V/P/HZ 380/3/50
Motor Power Ice Cutting Motor(kW) 1.5
Recircling Pump(kW) 1.5
Cooling Tower Model LX-30
Power(kw) 0.55
Cooling Pump Model GD65-19
Power 2.2
Cooling Fan Power Power(kW) 0.75
Water Cooling Machine Dimension L*W*H(mm) 1600*1400*2250
Refrigerant Quantity kg 100 120 140
Machine Weight kg 1800

| Product Packaging

tube ice machine packaging

5 ton tube ice machine packaging

tube ice machine packaging 1

10 ton tube ice machine packaging

tube ice machine packaging 230 ton tube ice machine packaging

| Company Profile

Hunan Icemedal Refrigeration Equipment Co., Ltd. is a research and development, production, sales and service in one of the professional refrigeration equipment manufacturing enterprises. The products mainly include cold room,Flake ice machine,cube ice machine, ice tube maker machine, block ice machine.

Adhering to the “Integrity, win-win, enjoy life” concept, has been committed to building modular boutique factory for customers,to provide customers with solutions for profit replication, so as to achieve our "Win-win" business value.

ice machine factory

| Comment & FAQ

1.Q:What is the ice making time of tube ice machine?

A:There are three sizes of pipe ice: pipe diameter 22mm, 28mm and 35mm, pipe diameter 22mm, ice making time 18-20 minutes; The pipe diameter is 28mm, and the ice making time is 20-22 minutes; The pipe diameter is 35mm, and the ice making time is 22-25mm minutes.

2. Q:What brand does the compressor use?

A:It mainly adopts two brands: German Bitzer compressor and American Valley wheel or as the customer request.

3.Q:What is the price?

A:The prices of various models are different. Please consult the salesman for details.

4.Q: Whats the deliver time of your machine?

A: 1~5ton, 30 days since the deposit arrived at our account. 5~20 ton, 45 days.(based on the electricity 380V/50Hz/3p. some special design lead time will be longer
