20 ton block ice machine is always used to build a containerized block ice plant. The advantages are acceptable price, low power consumption and convenient to move. Certification：CE MOQ：1 set Warranty：12 months Payment：T/T, Western Union, Money Gram, L/C Lead time：40 days after getting deposit After-sales Service Provided：Engineers available to service overseas | |||||||||
IMB20
Icemedal
The ice block machine is an ice machine that produces intermittent ice. The ice it produces is cuboid ice cubes, commonly known as ice blocks, and it is also an indirect cooling ice maker. The medium of brine is added between the ice-making water and the refrigerant to exchange heat. This makes the ice machine more stable and the shape of the ice is more adjustable.
| The Features of Icemedal Block Ice Machine
● Daily production: 20 tons per day.
● Coil pipe evaporator is our invention patent, it has a better evaporating effect with longer lifespan.
● High power water agitator is used to replace the common water pump. The block ice machine is energy saving. Ice making power consumption had declined from 110kW·h to 74kW·h/ton.
● Agitator makes the brine flowing faster, so that shorten the ice frozen time and improve the refrigeration effect of the whole machine. And agitator is much harder to be broken than water pump.
● Ice making tank adopts 80mm thickness polyurethane insulation material. It has good effect in heat insulation.
| Block ice Application
Blcok ice are widely used in ice plants, food processing, fresh preservation and cooling of aquatic products, ice sculpture, daily ice consumption, etc.
| Product Parameters
| IMB20 Block Ice Machine Parameters | ||
| Name | Unit | Parameter |
| Bitzer Compressor Parameter | Model | 4GE-23 |
Cooling Capacity(kW) | 33.9 | |
| Power(kw) | 14.05 | |
| Condenser | Model | WN-20 |
Heat Exchange(kW) | 74.2 | |
| Condensing Temperature | Degree Celsius(℃) | 38 |
| Evaporating Temperature | Degree Celsius(℃) | -18 |
| Ambient Temperature | Degree Celsius(℃) | 32 |
| Water Temperature | Degree Celsius(℃) | 20 |
Refrigerant | R507 | |
| Voltage | V/P/HZ | 380/3/50 |
| Agitator | Power(kW) | 2.2 |
| Cooling Tower | Model | LX-30 |
| Power(kW) | 0.55 | |
Cooling Pump | Model | GD65-19 |
| Power | 2.2 | |
Ice Mold Dimension | L*W*H(mm) | Customized |
Machine Dimension | L*W*H(mm) | Customized |
| Remarks | Crane is not included. | |
The ice block machine is an ice machine that produces intermittent ice. The ice it produces is cuboid ice cubes, commonly known as ice blocks, and it is also an indirect cooling ice maker. The medium of brine is added between the ice-making water and the refrigerant to exchange heat. This makes the ice machine more stable and the shape of the ice is more adjustable.
| The Features of Icemedal Block Ice Machine
● Daily production: 20 tons per day.
● Coil pipe evaporator is our invention patent, it has a better evaporating effect with longer lifespan.
● High power water agitator is used to replace the common water pump. The block ice machine is energy saving. Ice making power consumption had declined from 110kW·h to 74kW·h/ton.
● Agitator makes the brine flowing faster, so that shorten the ice frozen time and improve the refrigeration effect of the whole machine. And agitator is much harder to be broken than water pump.
● Ice making tank adopts 80mm thickness polyurethane insulation material. It has good effect in heat insulation.
| Block ice Application
Blcok ice are widely used in ice plants, food processing, fresh preservation and cooling of aquatic products, ice sculpture, daily ice consumption, etc.
| Product Parameters
| IMB20 Block Ice Machine Parameters | ||
| Name | Unit | Parameter |
| Bitzer Compressor Parameter | Model | 4GE-23 |
Cooling Capacity(kW) | 33.9 | |
| Power(kw) | 14.05 | |
| Condenser | Model | WN-20 |
Heat Exchange(kW) | 74.2 | |
| Condensing Temperature | Degree Celsius(℃) | 38 |
| Evaporating Temperature | Degree Celsius(℃) | -18 |
| Ambient Temperature | Degree Celsius(℃) | 32 |
| Water Temperature | Degree Celsius(℃) | 20 |
Refrigerant | R507 | |
| Voltage | V/P/HZ | 380/3/50 |
| Agitator | Power(kW) | 2.2 |
| Cooling Tower | Model | LX-30 |
| Power(kW) | 0.55 | |
Cooling Pump | Model | GD65-19 |
| Power | 2.2 | |
Ice Mold Dimension | L*W*H(mm) | Customized |
Machine Dimension | L*W*H(mm) | Customized |
| Remarks | Crane is not included. | |
